Indoor Dome Camera

SDPBA-1E66E

100pi No IR-2.png

★★★★★★

❖ OVERVIEW

This indoor dome camera is a standard 2 megapixel model.
The transparent dome has the diameter of Ø100mm. Its housing is designed with an aesthetically refined appearance and a non-reflective surface, reducing glare and unwanted light reflections. This ensures clearer images and minimizes interference that could impact performance, making it well-suited for both indoor and outdoor surveillance.

It is equipped with NDAA/TAA compliant SoC and Sony IMX307 sensor.
Featuring the motorized varifocal lens, the camera provides excellent flexibility and ease of installation, with an adjustable focal length of 2.7–13.5mm.

IP cam.001.png
렌즈 V_F.001.png
100 dome.001.png
  • 2 MP

  • Ø100mm Transparent Dome Cover

  • Plastic Housing

  • 2.7–13.5mm Motorized Varifocal Lens

  • 1/2.8" Sony STARVIS CMOS Sensor

  • Progressive Scan (16: 9)

  • Total Pixels: 1945 x 1109 (2.16 MP)

  • Effective Pixels: 1920 x 1080 (2.07 MP)

  • Full HD 1080p / HD720p @ 30 fps

  • IP NETWORK - Video Output

  • 2DNR / 3DNR

  • DOL HDR (Digital Over Lab High Dynamic Range)

  • WDR / DWDR

  • DC 12V & PoE - Power Source

  • Audio Input / Output (Optional)

  • Supports ONVIF

❖ NOTE

  • Easy Installation with any NVRs

  • Option: 6–22mm Motorized Varifocal Lens
