2MP | PoC

SDVBB-1E71P

100pi Vandal Dome Housing
2MP
Universal Output
WDR
Varifocal Lens
100pi Dome Cover Housing
Vandal-proof
IP66 Waterproof
PoC

CAMERA TYPE

Vandal Dome C​amera

​​

HOUSING

Aluminum Die Casting

​

SENSOR

1/2.9" SONY STARVIS CMOS Sensor (IMX307)

​​

LENS TYPE

2.7–12mm Motorized Varifocal Lens

​​​

IR LED

-

​​

POWER CONSUMPTION

100mA + 80mA (2 Motor Lens)

​​

VIDEO OUTPUT

AHD | TVI | CVI | CVBS

  • 1/2.9" SONY STARVIS CMOS Sensor (IMX307)

  • EYENIX EN771T

  • More than 50dB

  • Progressive Scan

  • 1920 x 1080 @ 25/30 fps | CVBS: 1280H

  • AHD | TVI | CVI | CVBS Selectable

  • AHD: Pelco-C(ACP) | TVI: Hikvision-C | CVI: HD-CVI or OSD Control​

  • Color: 0.09 Lux | B&W: 0.009 Lux

  • Power Superposition (SNM Multiple Power Supply)

  • External Input: DC 12V +/- 10%

4MP & 5MP | PoC

SDVBB-1G81P

100pi Vandal Dome Housing
4MP
Universal Output
WDR
Varifocal Lens
100pi Dome Cover Housing
Vandal-proof
IP66 Waterproof
PoC

CAMERA TYPE

Vandal Dome Camera

​​

HOUSING

Aluminum Die Casting

​

SENSOR

1/2.8" Sony STARVIS CMOS Sensor (IMX335)

​

LENS TYPE

2.7–12mm Motorized Varifocal Lens

​​

IR LED

-

​

POWER CONSUMPTION

150mA + 80mA (2 Motor Lens)

​

VIDEO OUTPUT

AHD | TVI | CVI | CVBS

  • 1/2.8" SONY STARVIS CMOS Sensor (IMX335)

  • EYENIX EN781

  • More than 50dB

  • Progressive Scan

  • 4MP (16:9), 2560 x 1440 @ 25/30 fps | 5MP (4:3), 2592 x 1944 @ 20 fps | CVBS: 1280H

  • AHD | TVI | CVI | CVBS Selectable

  • AHD: Pelco-C (ACP) | TVI: Hikvision-C | CVI: HD-CVI or OSD Control​

  • Color: 0.1 Lux | B&W: 0.01 Lux

  • Power Superposition (SNM Multiple Power Supply)

  • External Input: DC 12V +/- 10%
